6000 Series (1320KW-1680KW)
Product feature:
100% independent intellectual property rights
International mainstream Control Technology (EGS Engine Intelligent Management System)）
International advanced air-fuel ratio control technology (TECJET air-fuel ratio automatic regulation)
Large flow and high-pressure intake system can adapt to a wide range of concentration changes
Low-pressure intake and rarefied combustion control technology (suitable for low-pressure gas, better emission)
Advanced Genset management module (IG-NT automatic synchronization and automatic load distribution)
online maintenance technology (continuous trouble-free operation time more than 2500 hours)
Digital monitoring technology (full monitoring of engine thermal parameters and Genset electrical parameters)
Distributed energy system (electric-thermal system, electric-hot-cold system)
Specification of 6000 Series
The power range of China's gas engine is mainly from 200kW to 600kW, and the market demand for gas engines above 1000kW is very big. Series 6000 gas engine is a high-power gas engine developed by our company for this situation. Now the series of gas engine power can be up to 1600 kw. It adopts the most advanced technology of air-fuel ratio control, engine performance, fuel economy, reliability and security were greatly improved, and its main performance index has reached the international advanced level, can form a complete set of gas generator and compressor sets, meet the needs of urban and wellsite power supply and compressor markets.
| Engine model | Cylinders & Arrangement | Cylinder bbore,mm | Piston stroke,mm | Rated power ,kW | RPM,r/min | Total piston displacement,L | Heat consumption ratekJ/kW.h | Lub. oil consumption rate g/kW.h | Start method |
| H16V190ZLT-2 | 16 cylinders V type | 190 | 215 | 1320 | 1000 | 97.53 | ≤9500 | ≤1.0 | Gas/Electric start |
| H16V190ZLT-1 | 1680 | 1200 | |||||||
| Genset Model | Engine model | Alternator model | Power kW | voltage | RPM,r/min | Frequency Hz | Power factor | Dimension mm | Weight kg |
| 1100GF-T | H16V190ZLT-2 | 1100 | 400 | 1000 | 50 | 0.8 | 6520×2180×2540 | 19800 | |
| 1100GF1-T | H16V190ZLT-2 | JFG Series | 1100 | 10500 | 1000 | 6520×2180×2540 | 20500 | ||
| 1500GF-T | H16V190ZLT-1 | 1FC Series | 1500 | 480 | 1200 | 60 | 5998×2180×2540 | 19800 |
